What is the difference between curtain wall and doors and windows? - Top curtain wall, doors and windows manufacturer In China

Curtain wall and doors and windows have many similarities, but also have some differences in application. Today, Middle East Curtain Wall will talk to you about the difference between curtain wall and doors and windows. This article analyzes from three aspects: material characteristics, structural form and use purpose:

Core difference:

Doors and windows are essentially “hole enclosure components” on the building wall. They are installed in the reserved wall holes. Their main functions are opening and closing, ventilation, lighting, and separation of indoor and outdoor spaces. They also have certain insulation, heat insulation, sound insulation, and waterproof properties. Doors and windows are part of the wall.

Curtain wall is essentially a continuous “non-load-bearing external enclosure system” hanging on the outside of the main structure of the building. It is like a thin “skin” wrapped around the main structure of the building. It does not bear the load of the main structure (self-weight and external loads are transmitted to the main structure through connectors). Its main functions are enclosure (wind, rain, heat, sound), beauty, lighting, and providing building facade effects. Curtain wall is an external enclosure system independent of the wall.

Detailed comparative analysis of curtain walls and doors and windows:

Feature Dimension	Doors/Windows	Curtain Walls
Material Characteristics
* Frame Materials	Wood, uPVC (plastic), Aluminum Alloy (mainly thermal break), Steel (less common). Relatively smaller sections, thinner wall thicknesses.	Primarily Aluminum Alloy profiles, also Steel profiles, Stainless Steel profiles, Glass fins, Cable structures. Profiles have large sections, thick walls (typically ≥3mm), requiring high strength and stiffness.
* Panel Materials	Primarily Glass, sometimes screens, louvers, panels (e.g., aluminum panel windows). Usually single glazing (clear, tempered, insulating, Low-E, etc.).	Extremely diverse: Glass (single, insulating, laminated, Low-E, fritted, vacuum, fire-rated, etc.), Metal Panels (aluminum, steel, copper, titanium zinc), Stone (granite, marble), Composite Panels (terracotta, porcelain, fiber cement, polycarbonate), even fabrics, living walls. Diverse panel combinations.
* Sealing Materials	Rubber gaskets, sealants (e.g., silicone), foam sealants. Relatively lower requirements.	High-performance sealing systems: EPDM rubber gaskets, structural silicone sealants, weatherproof sealants, gaskets. Require high weather resistance, high elasticity, long lifespan to withstand greater movement and harsh environments.
* Connectors	Hinges, pivots, friction stays, handles, locks, primarily for operation and fixing.	Complex, high-capacity connection systems: Embeds, brackets, angles, bolts, stainless steel spider fittings (point-supported). Require precise design to transfer self-weight, wind loads, seismic loads to the primary structure.
Structural Form
* Relationship to Structure	Embedded within wall openings. Rely on the surrounding wall for support and fixing. Frame requires sealing/jointing to the wall.	Suspended/supported outside the primary structure (beams, columns, slabs). Connected reliably to the primary structure via dedicated connection components (e.g., embeds, brackets). A gap exists between the curtain wall and the primary structure (to accommodate movement).
* Load-Bearing Mechanism	Primarily bear self-weight and localized wind pressure at the opening. Loads are relatively small.	Bear self-weight, wind loads, seismic action, thermal movement, etc. Loads transfer path: Panel → Support Frame (mullions, transoms) → Connectors → Primary Structure. Do NOT bear primary structural loads.
* Structural System	Discrete, independent units. Each door/window unit is installed separately.	Continuous, integrated system. Composed of panels, support framing (vertical mullions, horizontal transoms), connectors, and sealing systems forming a continuous cladding surface covering large areas or the entire building facade.
* Movement Capability	Limited ability to accommodate opening deformation.	Must possess excellent movement accommodation capability (inter-story drift capability ≥ 1/100 ~ 1/200) to absorb deformation of the primary structure due to wind, earthquake, and thermal effects, preventing panel or frame damage.
* Typical Forms	Casement windows, sliding windows, top-hung windows, tilt & turn windows, swing doors, sliding doors, folding doors.	Stick-built (conventional) curtain walls (captured, structurally glazed, semi-captured), Unitized curtain walls, Point-supported glazing (glass fin, cable truss, space frame), All-glass systems, Double-skin facades (ventilated), Stone cladding, Metal panel cladding.
Usage & Purpose
* Primary Function	Opening/closing, ventilation, daylighting, visual connection, access/passage (doors), separation of indoor/outdoor spaces. Performance requirements (thermal, acoustic, waterproof) vary by building.	Building external envelope (weather barrier – wind, rain; thermal insulation; sound insulation; fire protection), Building facade design/aesthetics (appearance, modern feel, landmark status), Daylighting (large areas). Daily operation is NOT the primary focus (though operable vents exist).
* Application Location	Openings within walls. Primarily used for rooms, balconies, entrances – locations needing ventilation, light, or access.	Cover the entire building facade or large portions of it. Common on high-rises, skyscrapers, large public buildings (airports, stations, malls, offices, cultural centers) as the non-masonry exterior cladding.
* Scale	Relatively small. Size limited by opening dimensions and profile strength; single unit width/height is typically constrained.	Massive scale. Can cover single or multiple stories in height, span multiple bays horizontally. Forms a continuous, large-area building skin.
* Design Focus	Functionality (operation, ventilation, water/air tightness), Energy efficiency, Safety (security, fall prevention), Operability.	Structural safety (wind resistance, seismic performance), Envelope performance (water/air tightness, thermal, acoustic, fire), Aesthetic impact, Durability, Maintainability.

Summary of Key Differences:

Structural Role: Doors/windows are infill components for wall openings; curtain walls are independent external envelope systems suspended from the primary structure.
Scale & Continuity: Doors/windows are discrete and small-scale; curtain walls are continuous and large-scale building skins.
Structural Requirements: Curtain wall structural systems (frames, connectors) must be designed to withstand significantly higher loads (especially wind) and accommodate substantial movement of the primary structure. Material and construction strength, stiffness, and durability requirements far exceed those for standard doors/windows.
Material Diversity: Curtain wall panel material choices are vastly wider than for doors/windows.
Core Purpose: The core of doors/windows is operability and ventilation; the core of curtain walls is enclosure and facade expression. While operable vents exist in curtain walls, this is not their primary design intent.

Important Grey Areas:

Full-height Glass Doors/Windows: Large floor-to-ceiling glass doors or windows, especially those spanning multiple stories, may have structural forms and loading similar to curtain walls (e.g., point-supported glass or using curtain wall framing systems). The distinction becomes blurred and depends on their structural support and connection to the primary structure.
Curtain Walls with Operable Vents: Operable vents (casement, top-hung, sliding) can be integrated into curtain wall systems for localized ventilation. However, these vents themselves must meet curtain wall performance standards, and their construction is more complex than standard doors/windows.

Understanding these distinctions is crucial for architectural design, specification, construction, and maintenance. Simply put: if it’s a frequently operated, relatively small-scale component set within a wall opening, it’s a door/window. If it’s a large-scale, non-load-bearing “skin” hung outside the primary structure, primarily for enclosure and aesthetics, it’s a curtain wall.

Zhongdong Curtain Wall provides high-quality door and window system solutions. Whether you are looking for custom doors, Windows and curtain walls or aluminum alloy doors and Windows, our team will help you realize your vision. We will help you to provide an idealized Windows, doors and facades system for the appearance of your building, combining architectural aesthetics and functionality. If you are interested in glass facades or other facades, please Email us at monikachenwall@gmail.com or call us at: At +86-17727814139, we will arrange to contact you as soon as possible

Core difference:

Detailed comparative analysis of curtain walls and doors and windows:

Feature Dimension

Doors/Windows

Curtain Walls

Material Characteristics

* Frame Materials

Wood, uPVC (plastic), Aluminum Alloy (mainly thermal break), Steel (less common). Relatively smaller sections, thinner wall thicknesses.

Primarily Aluminum Alloy profiles, also Steel profiles, Stainless Steel profiles, Glass fins, Cable structures. Profiles have large sections, thick walls (typically ≥3mm), requiring high strength and stiffness.

* Panel Materials

Primarily Glass, sometimes screens, louvers, panels (e.g., aluminum panel windows). Usually single glazing (clear, tempered, insulating, Low-E, etc.).

* Sealing Materials

Rubber gaskets, sealants (e.g., silicone), foam sealants. Relatively lower requirements.

High-performance sealing systems: EPDM rubber gaskets, structural silicone sealants, weatherproof sealants, gaskets. Require high weather resistance, high elasticity, long lifespan to withstand greater movement and harsh environments.

* Connectors

Hinges, pivots, friction stays, handles, locks, primarily for operation and fixing.

Complex, high-capacity connection systems: Embeds, brackets, angles, bolts, stainless steel spider fittings (point-supported). Require precise design to transfer self-weight, wind loads, seismic loads to the primary structure.

Structural Form

* Relationship to Structure

Embedded within wall openings. Rely on the surrounding wall for support and fixing. Frame requires sealing/jointing to the wall.

Suspended/supported outside the primary structure (beams, columns, slabs). Connected reliably to the primary structure via dedicated connection components (e.g., embeds, brackets). A gap exists between the curtain wall and the primary structure (to accommodate movement).

* Load-Bearing Mechanism

Primarily bear self-weight and localized wind pressure at the opening. Loads are relatively small.

Bear self-weight, wind loads, seismic action, thermal movement, etc. Loads transfer path: Panel → Support Frame (mullions, transoms) → Connectors → Primary Structure. Do NOT bear primary structural loads.

* Structural System

Discrete, independent units. Each door/window unit is installed separately.

Continuous, integrated system. Composed of panels, support framing (vertical mullions, horizontal transoms), connectors, and sealing systems forming a continuous cladding surface covering large areas or the entire building facade.

* Movement Capability

Limited ability to accommodate opening deformation.

Must possess excellent movement accommodation capability (inter-story drift capability ≥ 1/100 ~ 1/200) to absorb deformation of the primary structure due to wind, earthquake, and thermal effects, preventing panel or frame damage.

* Typical Forms

Casement windows, sliding windows, top-hung windows, tilt & turn windows, swing doors, sliding doors, folding doors.

Stick-built (conventional) curtain walls (captured, structurally glazed, semi-captured), Unitized curtain walls, Point-supported glazing (glass fin, cable truss, space frame), All-glass systems, Double-skin facades (ventilated), Stone cladding, Metal panel cladding.

Usage & Purpose

* Primary Function

Opening/closing, ventilation, daylighting, visual connection, access/passage (doors), separation of indoor/outdoor spaces. Performance requirements (thermal, acoustic, waterproof) vary by building.

Building external envelope (weather barrier – wind, rain; thermal insulation; sound insulation; fire protection), Building facade design/aesthetics (appearance, modern feel, landmark status), Daylighting (large areas). Daily operation is NOT the primary focus (though operable vents exist).

* Application Location

Openings within walls. Primarily used for rooms, balconies, entrances – locations needing ventilation, light, or access.

Cover the entire building facade or large portions of it. Common on high-rises, skyscrapers, large public buildings (airports, stations, malls, offices, cultural centers) as the non-masonry exterior cladding.

* Scale

Relatively small. Size limited by opening dimensions and profile strength; single unit width/height is typically constrained.

Massive scale. Can cover single or multiple stories in height, span multiple bays horizontally. Forms a continuous, large-area building skin.

* Design Focus

Functionality (operation, ventilation, water/air tightness), Energy efficiency, Safety (security, fall prevention), Operability.

Structural safety (wind resistance, seismic performance), Envelope performance (water/air tightness, thermal, acoustic, fire), Aesthetic impact, Durability, Maintainability.

Summary of Key Differences:

Structural Role: Doors/windows are infill components for wall openings; curtain walls are independent external envelope systems suspended from the primary structure.

Scale & Continuity: Doors/windows are discrete and small-scale; curtain walls are continuous and large-scale building skins.

Material Diversity: Curtain wall panel material choices are vastly wider than for doors/windows.

Core Purpose: The core of doors/windows is operability and ventilation; the core of curtain walls is enclosure and facade expression. While operable vents exist in curtain walls, this is not their primary design intent.

Important Grey Areas:

Curtain Walls with Operable Vents: Operable vents (casement, top-hung, sliding) can be integrated into curtain wall systems for localized ventilation. However, these vents themselves must meet curtain wall performance standards, and their construction is more complex than standard doors/windows.
